Model No.

NVR-8000HGK-R16L

NVR-8000HGK-R16M

Operation System

LINUX O.S

Image Coding Control

Image Coding Quality can be adjusted, VBR/ CBR Optional

Dual Stream

Video Standard

H.265/H.264

Image Quality

4K/5MP/3MP/1080P/960P/720P

Image Dynamic Detection

Each image can be detected by multiple detection regions,  6 level sensitivity  can be setted(IPC support)

Image Playback

1/4/9/16 Sync. Playback

Privacy Mask

Each Channel support 4 Privacy Mask Areas (need IPC support);

Recording Mode

Support manual, automatic, dynamic monitoring, alarm trigger video mode

Backup

Support HDD, U disk, USB Mobile HDD, USB Record, Network Storage/ Backup(Partly need IPC support)

Operation Mode

Mouse, Keyboard Control

Local Login

UserName / Password

Recording Storage

Local HDD, Network

External

Network video input

① 64×1080P(1920*1080)

① 128×1080P(1920*1080)

② 64×3MP(2048*1536)

② 128×3MP(2048*1536)

③ 64×5MP(2592*1944)

③ 128×5MP(2592*1944)

④ 64×4K(3840*2160)

④ 128×4K(3840*2160)

Audio Input

1:1 Network Audio Input According To Network Video Channel Number

Video Output

2ch VGA+2ch HDMI

Audio Output

1ch RCA

Network Interface

2*RJ45

RS485 Interface

Full Duplex Standard 485 interface

USB Interface

1 USB 3.0 / 2 USB 2.0

Alarm Input

16ch

Alarm Output

16ch

HDD

HDD Interface

16 SATA+2 eSATA HDD Interface

Max Capacity

Each interface supports a maximum capacity of 6TB of hard disk

Mobile Surveillance

Support

Power Supply

ATX110-220V 300W 50-60Hz

Consumption

≤50W（without HDD）

Work Temperature

-10℃～＋55℃

Work Humidity

10％-90％

Dimension

NVR: 437mm×483mm×143 mm;  Packing: 605mm X 561mm X 280 mm

Weight(Without HDD)

NVR:  18.5KG

Carton

1pcs / carton, Dimension: 620mm X 570mm X 292mm

Installation

Desktop Installation, Stardard Rack Installation
